Maintenance and Service
Truck conveyor
7.12.2.3 Exchange weighing cell
ADVICE
Never mount the fixing screws (10) of the weighing cells (7) using an impact driver.
It may destroy the weighing cells. This is applicable for all major forces applied by
screwdrivers.
If it is necessary to replace a weighing cell, the work must be performed by authorised
service technicians.
(7) Weighing cell
(10) Weighing cell fastening nuts (76 Nm)
421 / 546
