Operation
Loading operation
(11) Skids under the central mark (adjustable)
Working too deep in the ground increases the power requirements of the pickup drive
and substantially increases roller wear! The depth setting must constantly be adjusted
to the ground profile and the load on the pickup by the beet weight.
6.14.5 Clearing shields
The clearing shields (1) limit the pickup width and guide the beets from sides onto the
pickup.
(1) Clearing shield
(2) Rubber skirt
When using the machine for the first time, set the rubber skirts (2) so that these just
barely contact the ground.
ATTENTION
During loading, especially watch out for frozen ground and built-up bulging soil in the
course of the clearing shield. Do not drive through obstacles with the clearing shields!
It might damage the folding mechanism.
254 / 546
