Maintenance and Service
Diesel engine
ADVICE
Corrosion protection/antifreeze agents are hazardous for the environment.
When handling these materials, always make sure that the corrosion protec-
tion/antifreeze agents do not enter the environment, but are disposed of in a manner
compatible to the environment.
Always make sure of sufficient antifreeze and only use corrosion protection/antifreeze
agents expressly permitted according to Mercedes-Benz factory standards 325.5 or
326.5. (See Page 516)
7.1.5.1 Cleaning of the cooling system
The cooling system is located over the diesel engine.
After folding down the rear wall of the platform the cooling system is easily accessible
from the boarding platform.
CAUTION
Falling hazard!
When working on the boarding platform always ensure that the safety rail on the
ladder is closed.
When cleaning the air intake grids or the coolers, always switch off the diesel engine
and secure it against inadvertent starting (pull off the ignition key and take it with you).
WARNING
Burning hazard!
Each cooler is heated up during operation.
Wear protective gloves!
Let the machine cool down sufficiently before starting any work on the cooling sys-
tems!
(1) Charge air cooler
(2) Hydraulic oil cooler
(3) Radiator
358 / 546
