List of relays
No. Ampere Occupation
Fr134.C 125mA B097 speed pinch roller 1 stone remover 9 V
Fr135.C 125mA B098 speed pinch roller 2 stone remover 9 V
Fr136.C 125mA B212 pressure sensor parking brake 9 V
Fr137.C 125mA S128 swivel arm lock 9 V
Fr138.C 125mA S125 ladder safety lock 9 V
Fr139.C 125mA B047 rpm driving speed 9 V
8.3 List of relays
No. Designation Position in
the machine
Comments Item No.
K001 Relay main load pin 15
in the central
electrics
Load relay ignition current pin 15,
power 70 A
320009900
K002.A Relay fan motor oil cooler PDG
on PCB A in the
central electrics
switches the fan 320015400
K002.C Relay electric pump fuel prefilter
on PCB C in the
central electrics
switches the fuel pump 320015400
K003 Relay direction indicator
in the roof con-
sole
flasher unit 320087100
K004 Relay fan module/park heating
in the central
electrics
320015400
K006 Relay window wiper
in the central
electrics
switches the front wiper motor 320057300
K017
Relay air conditioning control unit/
park heating
in the central
electrics
to switch from air conditioning control
unit pin 15 to pin 30
320015400
K043 Battery disconnect relay in battery case
electrically operated battery main
switch
320076200
