Operation
Left joystick
6.5 Left joystick
As soon as the left joystick console is folded up, the machine drive and the traction
drive stop automatically.
ADVICE
All functions can only be executed using the joystick if the seat console is swung all
the way down and the machine is operated in Turtle I or Turtle II mode or the machine
is operated in Rabbit I or Rabbit II mode with unlocked main steering switch.
Joystick movements
FORWARD Lower pile pickup
BACKWARD Raise pile pickup
LEFT Swivel pile pickup (completely) to the left
RIGHT Swivel pile pickup (completely) to the right
163 / 546
