Maintenance and Service
Pickup
7.8.4 Removing and installing rollers
(46) Central mark
(47) Frost breaker
(48) Fold plates
(49) Clearing shield
(50) Pinch roller 4
(51) Pinch roller 3
(52) Pinch roller 2
(53) Pinch roller 1
(54) Conveyor roller 3
(55) Conveyor roller 2
(56) Conveyor roller 1
(57) Cleaning roller
(58) Pickup roller
DANGER
Crushing hazard!
When removing and installing rollers, there is a risk that the pickup side parts may
suddenly fold in and severely injure anyone standing in this area.
Shut down the machine before carrying any maintenance and repair work.
Before starting work, the pickup side section must be securely supported or safely
attached to a crane with sufficient load capacity and additionally secured.
Shut down diesel engine.
Secure the diesel engine against accidental start-up, keep the ignition key out of
reach of any third party!
Observe the applicable accident prevention regulations for work under raised
loads.
