Operating Components
Operating console R-Concept
5.9.5 Keypad I
(10) Raise/lower additional axles: See Page 201.
The additional axles are lowered when the LED lights.
(11) Light - working lights: See Page 139.
(12) Functional key 1:
You can save different functions for the key (12) and call them up by pressing this key.
The assignment of the function keys can be changed in the menu "Basic settings",
submenu "Function keys". (Not active currently)
(13) Water spray system (option): See Page 284.
(14) Functional key 2:
You can save different functions for the key (14) and call them up by pressing this key.
The assignment of the function keys can be changed in the menu "Basic settings",
submenu "Function keys". (Not active currently)
(15) Oscillating axle support ON/OFF:
The oscillating axle support is on when the LED lights. (See Page 212).
(16) Swing axle left:
The load on the left rear axle is increased so long as this key is pressed.
(17) Swing axle right:
The load on the right rear axle is increased so long as this key is pressed.
