ROPA Maus 6 - Pickup Water Spray Nozzles

Operation
Water spray system (option)
ATTENTION
Risk of machine damage.
If the pressure reducer is set above 5 bar, the compressed air escapes through the
safety pressure valve (6 bar). The air compressor runs continuously due to such
incorrect operation and may overheat or even malfunction.
6.15.1.1 Pickup water spray nozzles
Pickup water spray nozzles on DUO water spray system (option)
(8) Outer spray nozzles on the pickup
(9) Central spray nozzles on the pickup
(10) Inner spray nozzles on the pickup
(11) Shut-off valves for central spray nozzles
