Operation
Loading operation
6.14.11 Conveyor rollers (drive E)
(See Page 256)
The conveyor rollers preclean the beets and guide them to the outside. A greater
cleaning effect is achieved due to the longer cleaning path.
The conveyor rollers always move in operating direction if the 4-part pinch rollers also
move in operating direction.
To switch on the conveyor rollers (can be switched on only together with the pickup
rollers), press the key (7) on the right joystick once briefly.
If this key is briefly pressed again, the conveyor rollers/pickup rollers stop. If this key
is pressed and held pressed, then the rotating direction of the conveyor rollers/pickup
rollers is reversed.
270 / 546
