Operating Components
Driver's cabin cylinder support
5.2 Driver's cabin cylinder support
The driver's cabin must not be raised or lowered unless both pickup side sections are
folded out and if the driver is sure that there is no obstacle within a height of 5.3 m
above the driver's cabin.
Cylinder support engaged
Cylinder support in parking position
DANGER
Risk of fatal injuries
The driver's cabin may lower without warning.
– The cylinder support (1) must be engaged before working under the driver's cabin.
– Return the cylinder support to parking position before lowering the driver's cabin.
WARNING
Risk of very serious injuries
– It is the responsibility of the driver to ensure that there is nobody in the area
between the safety rail at the boarding steps (2) and the cabin door when lifting or
lowering the cabin.
67 / 546
