Operation
Steering
If the all-wheel steer was not activated, then the cause of it is shown on the R-
Touch:
– Unlock main steering switch (44)
– Drive faster, the minimum speed (0.5 km/h) shouldn’t be reached.
– Driving speed too high. Please continue reducing the speed.
ADVICE
Once the main steering switch is opened in the operating mode "Rabbit", the speed is
reduced automatically for the safety reasons. If the keys (12) and (13) on the joystick
are pressed and held in such a way at too high speed and with opened main steering
switch, at first the speed is reduced automatically to the maximum activation speed,
then the function "All-wheel steer" becomes active. The keys can be released again.
In case you need to continue driving at a higher or maximum speed, please proceed
as follows:
– Set rear axle to central position (see following section)
– Lock the main steering switch
6.12.1.3 Put rear axle in central position
– Select operating mode "Rabbit"
– Drive slowly (below 12 km/h).
– Unlock main steering switch (44)
– Drive at least 0.5 km/h and press briefly the multi-key (11) on the joystick. Don't
hold it.
It sets the rear wheels straight.
Then, the main steering switch must IMMEDIATELY be locked again.
If the rear axle is not locked in central position, then during driving in the operating
mode "Rabbit II", the following warning icon is displayed on the R-Touch.
ADVICE
Once the main steering switch is locked, the rear wheels are immediately and auto-
matically straightened.
