ROPA Maus 6 - Layout Chart for a Beet Pile

Lists/Tables/Plans/Diagrams/Maintenance Verification
Layout chart for a beet pile
9.13 Layout chart for a beet pile
8.5 m <--- ---> 15 m
max. 10.2 m
(13 m)
2.55 m
4 m
(6 m)
Layout chart for 10 m wide beet pile
Approx. 15 m free space required at the beginning of a pile
Vehicle length: 14.97 m Vehicle width: 4.00 m Vehicle height: 3.00 m
Smaller piles should be
laid out central to the pickup
535 / 546
