Operation
Video system
6.21 Video system
WARNING
The video system is solely for assistance and may show obstacles in a distorted per-
spective, incorrectly or do not show at all. It is not a substitute for your attention. The
video system cannot display all objects that are very close and/or above the rear view
camera. It does not warn you about collision, people or objects. You are responsible
for the safety and must pay attention to your immediate surroundings. This applies
not only to the rear, but also to the area in front of and on the sides of the machine.
Otherwise you might not see people or objects, and continue driving, causing injures
to people or damage to property and the machine.
The video system could either fail or work incorrectly, when
it rains heavily, snows or is foggy.
the camera is exposed to very strong white light. White streaks may appear on the
screen.
the camera lens is dirty or covered.
The cameras are maintenance-free. When the image quality deteriorates, you should
clean the lens cover using a soft, clean and lightly moistened cloth. When cleaning,
make sure that you do not scratch the lens cover.
The images from the cameras can be displayed on the auxiliary terminal. You can
select the desired camera swiping sideways on the terminal (See Page 150). Images
of up to 4 different cameras can be displayed simultaneously.
The vehicle is equipped with the following cameras:
•
Back run camera (See Page 327)
•
Central mark camera (See Page 328)
Optional
•
Recleaner camera (See Page 330)
•
Truck conveyor camera (See Page 331)
Optional with R-Connect monitor
•
Cabin roof camera (See Page 329)
Optional with R-View
•
Rear area control camera left (See Page 332)
•
Rear area control camera right (See Page 332)
Automatic camera control
The video system switches to different views depending on the operating mode, the
position of the main steering switch, the driving direction and the driving speed. For
further information on operation and configuration, see (See Page 150). Depending on
the situation, the images of the most relevant cameras will be displayed automatically.
(e.g. the back run camera and R-View are displayed when reversing).
