Lists/Tables/Plans/Diagrams/Maintenance Verification
Lubricating plans
9.7.5 Central lubrication circuit 2 chassis with stone remover
View, part 1
25*
45
Drive shaft sieve conv. st. remover
25
25
Reversing lever pivot bottom
25*
75
75
105
25
45*
Turn swivel arm axial bearing bottom
Counterweight intermediate arm top
Counterweight intermediate arm bottom
Infeed conveyor drive shaft
Recleaner pivot bottom
Counterweight intermediate arm top
Swivel counterweight rod side
Reversing lever pivot top
105
105
Steer. knuckle right bottom
45
25
Steering cylinder right outside
45
45
Pile pickup up-down left
Pile pickup up-down right
Steer. cylind. left inside
Steering knuckle right top
Steering knuckle left bottom
Steering cylinder left outside
Rotate pile pickup top
Rotate pile pickup bottom
Steer. cylind. right inside
Steering knuckle left top
75
105
Rotate truck conveyor GE bearing bottom
105
25*
Rotate swivel arm chain lubrication
Rotate swivel arm chain lubrication
Rotate truck conveyor GE bearing top
Truck conveyor drive shaft
Rotate truck conveyor chain lubrication
Rotate truck conveyor chain lubrication
Sub-distributor swivel arm
ROPA item no.: 360017600
Sub-distributor chassis front
ROPA item no.: 360016500
Sub-distributor frame top
ROPA item no.: 360017500
Main distributor lubricating circuit 2 chassis
Reconstructed from ROPA item no. 360017400
Lubricating circuit 1 support
105
105
Counterweight arm GE bearing bottom
Swivel arm GE bearing top
Counterweight arm GE bearing top
Turn swivel arm GE bearing
105
105
Steering knuckle right top
45
25
Steering cylinder right outside
105
45*
Recleaner pivot bearing bottom
Axle bracket bearing front
Steer. cylind. right inside
Steer. knuckle right bottom
Steering knuckle left top
Steering cylinder left outside
Axle bracket bearing rear
Steer. cylind. left inside
Steering knuckle left bottom
Sub-distributor chassis rear
ROPA item no.: 360016600
To the sub-distributor
Stone remover (see next page)
523 / 546
