Operating Components
Operating console R-Concept
5.9.6 Keypad II
(18) STOP diesel engine:
This key shuts the diesel engine down.
(19) START diesel engine:
This key starts the diesel engine (must be held for at least 3 sec.).
(20) Switching operating mode "Turtle/Rabbit":
See Page 186
(21) Switching between I/II gear of the operating mode:
Operating mode gear I - all-wheel drive is automatically switched on.
Operating mode gear II - all-wheel drive is automatically switched off.
See Page 186
(22) Differential lock front axle ON/OFF:
The differential lock is on when the LED lights. (See Page 187)
(23) Differential lock ON/OFF:
The differential lock is on when the LED lights. (See Page 187)
(24) Service key
This key is used by service personnel, e.g. for diagnostic purposes.
(25) Window wipers (all except for the windscreen): See Page 129
90 / 546
