Lubricating plan (lubrication with grease gun)
9.3 Lubricating plan (lubrication with grease gun)
Lubricating point Number of
nipples
Every oper.
hrs.
Telescopic pile pickup (coat with grease) 4 when
required
Fold in pickup hydraulic cylinder joint head 2 100
Bolt on fold pickup cylinder 2 100
Raising pickup hydraulic cylinder joint head 2 100
Support foot pivot left and right 2 100
Residual beet pickup pivot 2 100
Pile pickup hydraulic cylinder joint head right/left 4 100
Pile pickup hydraulic cylinder joint head up/down 2 100
Front additional axle self-steering 2 100
Cylinder axle support 4 100
Additional axles rear-front cylinder load 8 200
Locking lever swivel arm roller 1 200
Locking lever swivel arm pivot 1 200
Universal joints in front and rear axles 8 200
Cardan shafts from gearbox to axles 4 200
Nipple block beside tank support 8 200
Turn intermediate lever for residual beet pickup sensor 1 annually
Counterweight arm locking lever 4 annually
Under-run protective device pivot 2 annually
Rear recleaner attachment 6 200
Rotate recleaner cylinder joint head 1 200
Pivot point of scale interm. frame in truck conv. articulated part 2 200
Bearing on truck conveyor weighing frame 2 200
Bearing on weighing cell connecting lever 2 200
ADVICE
All lubricating points must also be lubricated after each washing of the machine. After
washing of the machine, the central lubrication system must also be lubricated using
at least 2 intermediate lubrication cycles. To do this, run all drives at low speed.
Grease ROPA item no. 435006200 (See Page 515)
as per DIN 51825, NLGI-class 2, type: KP2K-20,
at low outdoor temperatures KP2K-30.
No lubricating greases containing solid lubricants may be employed. Biologically
degradable greases are also admissible.
