Operation
Folding the machine out/in
6.13.5 Folding out machine manually in front
If the automatic folding does not operate, the machine can be "manually" folded step
by step to loading or transport position.
– Switch to the "Turtle I" operating mode. (See Page 186)
– Before folding out, remove securing chains for the pickup and insert them into the
hooks on the vehicle frame provided for this purpose.
ATTENTION
Risk of machine damage.
Do not intentionally lower the pickup into the securing chains.
– Switch on the oscillating axle support for the rear axle before folding out the
machine. (See Page 212)
220 / 546
