Operation
Pump distributor gears
6.17 Pump distributor gears
The pump distributor gears is directly flanged to the diesel engine and transfers engine
power to the individual hydraulic pumps. The hydraulic pumps required for loading are
connected by a multiple disc clutch. Briefly press the yellow key (6) on the right joystick
to switch this clutch and thus the machine drive on and off.
The pump distributor gears are fitted with pressure circulation lubrication. If lubrication
is not sufficient, then a warning signal sounds.
The R-Touch shows the warning icon .
ATTENTION
Hazard of severe damage to the machine.
– Immediately shut down the diesel engine if the warning signal sounds while the
diesel engine is running.
ADVICE
The highest allowed engine rotating speed for the drive of hydraulic pumps may not
be exceeded, not even for a short time.
Maximum rotating speed:
Machine drive switched on: 1,975 rpm
Machine drive switched off: 2,700 rpm
(in overrun mode with active constant throttle brake)
