ROPA Maus 6 - Quick Description: Steering in the Rabbit Operating Mode

Operation
Steering
6.12.1.4 Quick description: steering in the "Rabbit" operating mode
Start diesel engine.
↓
Select the "Rabbit"
operating mode.
↓
L
R
Drive slowly (below 12 km/h).
↓
Unlock the main steering switch.
↓ ↓
Rear wheels may be steered to the
left (L) or right (R) using the joystick.
↓
Drive at least 0.5 km/h.
↓
Press the multifunctional key (11) or
lock the main steering switch (44).
Activate theall-wheel steering.
For this purpose, press and hold
keys (12) and (13) simultaneously
while driving until the all-wheel
steering appears in the Steer-
ing display field of the R-Touch.
↓
The rear wheels are set straight
and remain in this position.
↓
↓
11
13
12
14
Important: lock the main steering switch. If the rear wheels are not
in 0°-position or the main steering switch is not locked, then cor-
responding warning messages are displayed on the R-Touch:
or
210 / 546
