Operating Components
Operating console R-Concept
5.9.4 R-Direct
The R-Direct function area (5) (YELLOW operating panel colour) allows the driver to
perform different settings, e.g. access to the main menu with submenus. The R-Touch
main terminal accepts commands when you touch one of the R-Direct selecting fields
(5) as well as when you turn or press wheel on the R-Direct (5a).
(6) RETURN–key:
With the RETURN-key you can leave each R-Direct menu gradually.
(7) OPT–key:
Use this key to open the quick access window. (See Page 114)
(8) HOME–key:
Click here to go back to the start screen.
(9) C–key:
With the C-key you can delete any entered information (Delete). When a warning indi-
cator activates the warning buzzer, you can suppress the sounding of the buzzer for a
short period pressing the C-key (9).
88 / 546
