Operation
Video system
6.21.6 R-View cameras (option)
Your machine can be fitted with the optional "R-View" video system. The images of
the rear area control camera left and the rear area control camera right are displayed
together with the back run camera. The image shows the environment around the rear
part of the machine.
ATTENTION
The R-View cameras might not display some obstacles, e.g. branches of trees, on the
top rear corners of the machine. You can see obstacles on the monitor up to a height
of about 3 metres above the ground.
ATTENTION
When driving along the edge of the forest, hedges, etc., pay attention to these side
cameras. On both cameras, the outer piece (with the holders centred by springs) can
deflect a little to the rear and front. Then, they automatically swivel back into the start-
ing position.
The cameras have normal holders, which can not bend tree-branches! Large tree-
branches could damage camera holders and the machine. Such damage is not cov-
ered by the warranty!
332 / 546
