Operation
Folding the machine out/in
6.13.8 Folding in the machine manually in front
The condition is that the machine rear is completely folded in and the truck conveyor
rests on the transport support.
WARNING
Hazard of extremely severe injuries.
– Make sure, that nobody stands in the hazard zones when the machine is started.
– Make sure that there are no persons on the boarding platform.
– The driver is responsible for ensuring that there is nobody in the area between
the safety rail at the boarding steps and the cabin door when lifting or lowering the
cabin.
– Swing the pile pickup to the center and raise it as far as possible. (See Page 163)
– Telescopically extend pile pickup about half-way.
– Turn the residual beet pickup to the central position.
– Raise the central part of the pickup as high as possible. For this purpose, pull the
mini joystick (1) on the right joystick backwards.
243 / 546
