ROPA Maus 6 - Pcb C

Malfunction and Remedies
Fuses
8.2.6.3 PCB C
No. Ampere Occupation
F006.C 20 A003 power supply outputs
F007.C 20 A003 power supply outputs
F008.C 20 A003 power supply outputs
F009.C 10 K002.C relay electric pump fuel prefilter
F010.C 5 A003 power supply CPU
Pin 30
PCB
Self-resetting electronic fuses with LED
Fr101.C 125mA B026 PS traction drive forward 24 V
Fr102.C 125mA B084 PS traction drive backward 24 V
Fr103.C 125mA not used 24 V
Fr104.C 125mA B009 sensor driving pedal 1 24 V
Fr105.C 125mA B032 drive pedal sensor (safety) 24 V
Fr106.C 125mA B061 pressure sensor brake-pressure service brake 24 V
Fr107.C 125mA B085 pressure sensor PDG coupling 24 V
Fr108.C 125mA B022 pressure sensor recleaner 24 V
Fr109.C 125mA B010 pickup depth sensor 24 V
Fr110.C 125mA B076 fold pickup right 24 V
Fr111.C 125mA B077 fold pickup left 24 V
Fr112.C 125mA B067 pressure sensor pickup relief centre 24 V
Fr113.C 125mA B068 pressure sensor pickup relief right 24 V
Fr114.C 125mA B069 pressure sensor pickup left 24 V
Fr115.C 125mA B070 pile pickup height sensor 24 V
Fr116.C 125mA B008 pile pickup side sensor 24 V
Fr117.C 125mA B094 sensor telescopic pile pickup 24 V
Fr118.C 125mA not used 24 V
Fr119.C 125mA not used 24 V
Fr120.C 125mA not used 24 V
Fr121.C 125mA not used 24 V
Fr122.C 125mA not used 24 V
Fr123.C 125mA not used 24 V
Fr131.C 125mA B072 speed infeed conveyor 9 V
Fr132.C 125mA B066 cleaning speed 9 V
Fr133.C 125mA B071 speed truck conveyor 9 V
