Operation
Electrical system
6.22 Electrical system
6.22.1 Voltage monitoring
The battery voltage is monitored by the system. If the voltage is too high or too low,
then the warning icon is displayed on the R-Touch. The battery voltage may not
exceed 32 V and may not fall below 24 V. As experience has shown, the machine can-
not be started with a battery voltage of less than 24 Volts.
When the generator fails, the following icon appears on the R-Touch.
