Operation
Loading operation
Speed of conveyor rollers
Choose this function with R-Select.
+ key = increase speed (rollers rotate faster)
- key = decrease speed (rollers rotate slower)
To treat the beets as carefully as possible, the speed of the conveyor rollers should
not be selected higher than necessary.
At a higher speed of the conveyor rollers, many beets are transported all the way to
the outside. Thus, the cleaning path is extended. It is recommended if the beets are
highly soiled.
The speed of the eccentric drive of the central mark is synchronous to the speed of
the conveyor rollers (due to series connection of the hydraulic motors).
If the warning limit of the conveyor rollers is exceeded, the following warning icon is
displayed on the R-Touch.
If the conveyor rollers are blocked, then the following warning icon is displayed on
the R-Touch.
If the conveyor rollers are blocked, the pickup roller drive is switched off.
271 / 546
