Operation
Left joystick
Mini joystick (15)
FORWARD Telescopically extend pile pickup
BACKWARD Telescopically retract pile pickup
LEFT Rotate residual beet pickup to the left
RIGHT Rotate residual beet pickup to the right
X-Y key (16)
Only in the operating mode "Turtle"
FORWARD Increase diesel engine speed
BACKWARD Reduce diesel engine speed
LEFT Loading direction to the left (the truck is positioned on the left side
of the machine)
RIGHT Loading direction to the right (the truck is positioned on the right
side of the machine)
Preselect right/left loading direction. In order to switch over, push the X-Y key (16) in
the required direction and hold it briefly in the end position.
ADVICE
If the X-Y switch (16) is pressed to the left/right and held briefly, the direction of rota-
tion of the swivel arm is reversed.
With automatic folding function, the preselected loading direction determines the des-
tination of the truck conveyor (See Page 214) when folding out.
