Operation
Folding the machine out/in
WARNING
Hazard of extremely severe injuries.
– Make sure, that nobody stands in the hazard zones when the machine is started.
The following processes are executed automatically. During these processes,
several movements are performed simultaneously:
1 The speed of the diesel engine increases.
2 The counterweight is raised up to the end-stop.
3 The lock of the counterweight arm opens up to the end-stop.
4 The counterweight arm swivels a little to the left thereby enabling complete opening
of the lock.
5 The truck conveyor is raised only slightly above the lateral transport support.
6 The truck conveyor turns to the right and out of the machine perimeter.
7 The recleaner swivels into working position.
8 The swivel arm is unlocked.
9 The truck conveyor is raised, simultaneously the truck conveyor articulation is
swung up.
10 With the pre-selected "Loading direction left", the completely lowered truck con-
veyor crosses over with the counterweight (lift up to the end-stop) at the rear of the
machine.
11 As soon as these processes are completed, the diesel engine switches to idling
speed.
If automatic folding is not entirely completed, you can intervene at any time and
complete the folding process manually. (See Page 225)
ATTENTION
Always pay attention that there is sufficient free space behind the machine allowing
implementation of this movements. In addition, there must be sufficient ground clear-
ance.
