Operation
Folding the machine out/in
– Insert the safety chains and secure the pickup. There is one safety chain for the
right side and one safety chain for the left side of the front chassis. When driving
on public roads, these chains must be fastened to the pickup central part. Fasten
the chains on the central part of the pickup, when you have swung in the pickup
and are leaving the machine. In case of a malfunction of the hydraulic system, the
pickup cannot drop unexpectedly. Otherwise, this could result in serious damage
to the driver's cabin! Such damage is excluded from any guarantee, warranty or
accommodation.
Switch into the operating mode "Rabbit". The warning signs are automatically swung
down and the ladder is swung into the vehicle contour.
The additional axles are to be activated as soon as the vehicle is located on a paved
road.
ADVICE
Such processes as lifting of the support feet and folding of the clearing shield are
time-controlled. If the hydraulic oil is very cold, the automatic folding system might not
be able to move the support foot or clearing shield as far as it can go. In this case,
please move it manually. Otherwise, the external width or the overall height could be
exceeded.
