Operation
Loading operation
The pickup must be lowered before swivelling the pile pickup far to the right or left. If
the pickup is not lowered sufficiently, the R-Touch shows the following icon .
Before picking up remaining beets, we recommend lowering the pickup a few centime-
tres at very low speed and picking the remaining beets as follows:
– Always pull the beets to the conveyor rollers at the central mark. To do this move
the remaining beet pickup parallel to the conveyor rollers and wait until the beets
are transported to the infeed conveyor.
– Then pull the outside beets over the conveyor rollers. With some practice it should
be possible to pickup the remaining beets in six actions.
ADVICE
Tip! Always work around the central mark when picking up remaining beets and
always from the centre of the pickup to the outside.
Beets lying on the edge can be picked up more easily if the clearing shields are
folded in.
