Operation
Central lubricating system
Regularly check the lubricating pipe system. Check the lubricating system daily for
faults. One option is to check the two or three main distributors. An indicator pin is
installed there for checking the function. This indicator pin moves slowly when the
grease flows through the main distributor. This shows whether the pump element of
this lubricating circuit is operating. This check can be carried out safely with the inter-
mediate lubrication.
Pickup main distributor (right side of the
pickup central section)
Chassis main distributor (right next to
lubrication pump)
Main distributor for 8-set pinch rollers
cleaner (on the left of the recleaner
frame)
(1) Indicator pin
