Maintenance and Service
Recleaning
1
2
2
3
(1) Fixing screw
(2) Lock nut
(3) Tensioning bolt
– Loosen the fixing screws (1) for the deflector rollers on the right and left.
– To tension the belt loosen the lock nuts (2) on the two tensioning bolts (3) on the
right and left.
– Turn the lock nuts as far as necessary and tighten them.
– Make sure that the tensioning bolts are adjusted equally on both sides to tension
the belt evenly.
