Maintenance and Service
Truck conveyor
If the truck conveyor is crooked, it can be made even by adjusting the clamping nuts
(4) on the diagonal strut (5) in the conveyor infeed.
Synchronism
If the truck conveyor belt is severely one-sided on the side flange of the drive wheels,
it can be synchronised by moving the counter bearing (7) of the drive shaft (8).
(7) Counter bearing truck conveyor drive shaft
(8) Truck conveyor drive shaft
(9) Clamping nut
(10) Fixing screws
416 / 546
