Maintenance and Service
Truck conveyor
Check the chain wear one a year as described below and replace the chain immedi-
ately it reaches the wear limit (305 mm).
DANGER
Hazard of fatal injuries by uncontrolled rotary movements of swivel arm and
truck conveyor if the chain jumps off the sprocket.
– Stop the machine immediately and have the machine checked by a mechanic.
Rotating swivel unit chain drive
423 / 546
