Malfunction and Remedies
Fuses
No. Ampere Occupation
F028 reserve
F029 10 Hazard warning system
F030 10 24V power supply voltage transformer 1
F031 15 Pin 30 for radio (DIN chute roof console)
F032 20 Window wiper right front
F033 20 Window wiper right rear
F034 20 Rear window wiper
F035 20 Window wiper door
F036 15 Driving light power supply
F037 20 Window wiper left rear
F038 20 Window wiper left front/coding
F039 reserve
Pin 30
from X2
F051 15 Front window wiper
F052 30 Heater fan
F053 10 Hazard warning system
F054 3 Ethernet switch 1
F055 3 Generator, battery relay
F056 3 A019 air conditioning control unit
F057 15 Heating fuel prefilter/air dryer heater
F058 10 24V power supply voltage transformer 2
F059 5 Ethernet switch 2/rear area control camera
F060 3 Computer scales
F064 7.5
ACM/MCM/weighing cells, inclination sensor/swivel arm
path measuring system, rotate truck conveyor
Pin 15
F070 5 Battery relay/battery emergency shutdown
F071 10
Computer telematics/diagnosis park heater/power supply
before main switch
Pin 30 in
front of
main switch
F075 7.5 Roof console/seat console 12 V
F076 7.5 Outlet 12 V cooling box 12 V
F080 7.5 Parking light right
F081 7.5 Parking light left, instrument lighting
from driving
light F036
