Rovema CMK Operator’s Manual
Section 5: Operator Controls
200246 CMK Operators Manual (02/06/2006) 5-38
HMI (Human-Machine-Interface)
PLS (Programmable Limit Switch) Config
A PLS channel allows the operator to adjust the amount of time that an area of
the machine is activated as required for production. These PLS Configuration
screen values are used to compensate for the delay in the solenoids valves.
These values should only be adjusted by properly trained personnel.
These screens are accessed from the Configuration Screen of the HMI.
Figure 5.44
Shows the Config screen Screen 1 of 2
