Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-44
Main Drive
Tensioning the Main Drive Belt
To Tension the Main Drive Belt:
• Loosen the fastening screws (4).
• Turn the tension screw (5) to move the entire unit.
• Turn in the tension screw (5) until the desired tension of the drive belt (1)
has been reached.
• Tighten the fastening screws (4).
Figure 7.36
Tensioning the main drive belt.
