ROVEMA CMK - Flap Closer Adjustments

Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-32
Flap Closers
Flap Closer Base Settings
Side flaps are inserted through the recess. The side flap must be received
approximately in the center of the recess. This setting should be checked in JOG
mode.
If the disk is not aligned properly, loosen the clamping screw (1) and rotate the
disk to the proper position. Re-check it in JOG mode.
Figure 7.24
Adjusting the Flap Closers.
