Carton Supply
Supply Conveyor Tension
The tension of the carton supply conveyor can be adjusted with the threaded
bolts. Turning the bolts moves the conveyor deflection roller forward or
backward.
Figure 7.5
Conveyor tension bolts.
Conveyor Tension
Bolts
