ROVEMA CMK - Hold down Device

Rovema CMK Operator’s Manual
Section 4: Parts and Functions
200246 CMK Operators Manual (02/06/2006) 4-8
Hold Down Device
The carton is held in place by the hold-down device to prevent it from being
erected inside the magazine. The hold-down devices should be about 10mm
away from the flap imprint (fold) in the direction towards the center of the carton.
To adjust the location of the hold down device, loosen the bolts on the fastening
device and move the hold-down device into position. When it is in the proper
position, tighten the bolts.
Figure 4.9
Shows the hold down device.
Hold Down Device
Adjustment
Bolts
