Carton Removal Chain
Tensioning the Chain Removal Drive Belts
The drive belt (3) runs over a tension roller (2). This roller can be moved by
loosening the clamping screw (1). Loosening the clamping screw and pressing
down the tension roller tensions the belt. After the tensioning is complete, tighten
the clamping screw.
Figure 7.38
Tensioning the drive belts.
