Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-4
Carton Dimensions
The below illustration provides the location of the dimensions on the carton that
corresponds to the dial settings labeled on the machine. There are several blank
forms on the next several pages which may be used to record the settings.
Figure 7.3
Carton Illustration with locations to measure for dial and scale settings.
Flow of
Production
Dial: #15
Dial:
#10, #11, & #12
Dial: #13
Dial: #14
Scale: #6
Scale: #7
Dial: #1 & #4
Dial: #3
Scale: #9
Scale: #9
Scale: #8
Scale: #8
Scale: #2
& Dial #5
Dial: #17
