Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-47
Carton Removal Chain
Tensioning the Removal Conveyors
Loosening the fastening screw (1) makes it possible to move the sprocket (2) in a
slot to tension the chain. The tension must be the same on the two chains. After
tensioning is complete, check the position of the drivers (3). The two drivers must
line up with each other on the mark for the zero setting.
Figure 7.39
Tensioning the Removal Conveyors.
