Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-38
Bucket Conveyor
Adjust Bucket Conveyor - Continued
After loosening the mechanical coupling, go to the beginning end of the bucket
conveyor, located on the end furthest away from the carton machine, as shown in
the picture below. Use the special wrench to turn the conveyor to the desired
width.
After the bucket size is adjusted, the bucket conveyor must be locked in place by
tightening the mechanical coupling previously loosened. Check the width setting
of the buckets after the machine has been running for a short time!
Figure 7.30
Adjusting the bucket size.
Adjustment
Location #19
Adjustment Cylinder
Wrench on
Cylinder
Buckets
Adjust in Size
