Rovema CMK Operator’s Manual
Section 5: Operator Controls
200246 CMK Operators Manual (02/06/2006) 5-9
HMI (Human-Machine-Interface)
Carton Magazine Parameters Descriptions
Carton Magazine Parameters
Parameter Description
Carton Magazine Start Delay This determines the amount of time that the conveyor will
wait, before advancing, to add more cartons into the carton
magazine after receiving a signal form the carton magazine
low carton detector.
Carton Magazine Stop Delay This determines the amount of time that the conveyor will
continue advancing to add more cartons to the carton
magazine after receiving a signal form the carton magazine
low carton detection device.
Carton Magazine Empty Count The number of cycles that the machine is allowed to run
after detecting that the magazine is low.
Figure 5.10
Carton Magazine Parameter Descriptions
