Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-24
Carton Chain
Position Drivers Vertically
It is important for all drivers (2) to be positioned vertically while the carton is
being moved so that the carton maintains a rectangular shape.
This vertical position can be achieved with a narrow chain guide (5) under the
carton holding surface (6). The setting screws (4) make it possible to set the
chain guides. This makes up for signs of wear on the rails.
To adjust the chain guide:
• Loosen the lock nut (3)
• Screw in the adjustment screw (4) until the chain has the right amount of
play in it.
Figure 7.16
Positioning Drivers.
