Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-17
Drive Chain
Chain Tension Drive Chain
The tension of the driver chains can be adjusted with a tension screw (one for
each chain). Loosen the lock nut (3) and adjust the sprocket (2) with the tension
screw (4) until the required tension is reached. Tension the driver chain (1) so
that it is taut and is inside the closed guide.
The tension of the chains must be the same on both sides.
Figure 7.9
Chain Tension
