Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-35
Drying Zone
Drying Zone Adjustments
The carton should run easily through the drying zone without too much friction
against the rounded rods (1) as it is drawn along. The pressure exerted on the
carton by the rounded rods must be great enough to press on the flaps. Run the
machine in JOG mode to check these settings.
The rounded rods can be adjusted in the slots (2) after loosening the clamping
screws (3). After a change, a carton should be moved through the machine in
JOG mode to check all settings
Figure 7.27
Drying Zone Adjustments.
