Rovema CMK Operator’s Manual
Section 4: Parts and Functions
200246 CMK Operators Manual (02/06/2006) 4-12
Carton Conveyor
A carton chain is used inside the machine to move the opened cartons. This
chain consists of four individual chains.
The cartons are transferred from the draw-off chain onto the carton chain. The
cartons are erected by the flights and transferred through the machine. The
flights hold the cartons in a rectangular shape until they are filled and closed.
Figure 4.13
Shows a carton in the drivers.
Flights
Flights
Chain
