ROVEMA CMK - Filling Height Monitoring; Adjusting Fill Height Monitoring

Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-42
Bucket Conveyor
Filling Height Monitoring
Filling height monitoring is used to monitor the height of product in the bucket.
Adjusting Fill Height Monitoring:
Loosen the clamping lever (5).
Move to desired location on the scale (3) as indicated by the arrow below.
Figure 7.34
Adjusting the bucket conveyors Fill Height Monitoring height.
