Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-29
Barrel Loader
Insertion Slides Cover Guide
To remove the insertion slides cover, pull down and turn the locking knob to hold
it open, pull the guide off the bracket.
Figure 7.21
Replacing Insertion Slide covers.
Pull Down and
Turn Knob
Pull Cover from
Bracket
